Overlay

Demonstrates the Overlay and OverlayEntry widgets for managing layered content. Press 'a' to add an entry, 'r' to remove the last entry, 'c' to clear all ent...

Preview

Code

pkgs/artisanal_widgets/example/overlay/main.dart

// Overlay Example
import 'package:artisanal_widgets/artisanal_widgets.dart';
//
// Demonstrates the Overlay and OverlayEntry widgets for managing layered
// content. Press 'a' to add an entry, 'r' to remove the last entry,
// 'c' to clear all entries.
//
// Run with: dart run example/overlay/main.dart

import 'package:artisanal/style.dart' hide Padding, Align;
import 'package:artisanal/tui.dart' as tui;
import 'package:artisanal_widgets/widgets.dart' as w;

void main() async {
  final app = WidgetApp(OverlayDemo());
  await tui.runProgram(
    app,
    options: const tui.ProgramOptions(
      altScreen: true,
      mouseMode: tui.MouseMode.allMotion,
    ),
  );
}

class OverlayDemo extends w.StatelessWidget {
  OverlayDemo({super.key});

  @override
  w.Widget build(w.BuildContext context) {
    return w.Overlay(
      initialEntries: [w.OverlayEntry(builder: (_) => _OverlayDemoHost())],
    );
  }
}

class _OverlayDemoHost extends w.StatefulWidget {
  _OverlayDemoHost();

  @override
  w.State createState() => _OverlayDemoHostState();
}

class _OverlayDemoHostState extends w.State<_OverlayDemoHost> {
  int _entryCount = 0;
  final List<_EntryInfo> _entries = [];
  final List<w.OverlayEntry> _overlayEntries = [];
  final w.WidgetScrollController _scrollController = w.WidgetScrollController();

  static final _colors = [
    (Colors.red, 'Red'),
    (Colors.green, 'Green'),
    (Colors.blue, 'Blue'),
    (Colors.cyan, 'Cyan'),
    (Colors.magenta, 'Magenta'),
    (Colors.yellow, 'Yellow'),
  ];

  @override
  tui.Cmd? handleUpdate(tui.Msg msg) {
    if (msg is tui.KeyMsg) {
      if (msg.key.char == 'q') return tui.Cmd.quit();
      if (msg.key.char == 'a') {
        final colorIdx = _entryCount % _colors.length;
        final info = _EntryInfo(
          id: _entryCount,
          color: _colors[colorIdx].$1,
          name: _colors[colorIdx].$2,
        );
        final overlayEntry = _buildOverlayEntry(
          info,
          stackIndex: _entries.length,
        );
        setState(() {
          _entries.add(info);
          _overlayEntries.add(overlayEntry);
          _entryCount++;
        });
        w.Overlay.of(context).insert(overlayEntry);
        return tui.Cmd.repaint();
      }
      if (msg.key.char == 'r' && _entries.isNotEmpty) {
        final removedEntry = _overlayEntries.removeLast();
        setState(() => _entries.removeLast());
        removedEntry.remove();
        return tui.Cmd.repaint();
      }
      if (msg.key.char == 'c') {
        final removedEntries = List<w.OverlayEntry>.from(_overlayEntries);
        setState(() {
          _entries.clear();
          _overlayEntries.clear();
        });
        for (final entry in removedEntries) {
          entry.remove();
        }
        return tui.Cmd.repaint();
      }
    }
    return null;
  }

  w.OverlayEntry _buildOverlayEntry(
    _EntryInfo entry, {
    required int stackIndex,
  }) {
    return w.OverlayEntry(
      builder: (ctx) {
        final theme = widget.theme;
        final label = theme.labelSmall.copy()..foreground(theme.onBackground);
        final entryStyle = Style()..foreground(entry.color);
        return w.Positioned(
          top: 8 + (stackIndex * 4),
          right: 3,
          child: w.Container(
            padding: const w.EdgeInsets.all(1),
            decoration: w.BoxDecoration(
              border: Border.normal,
              color: theme.surface,
            ),
            child: w.Column(
              gap: 0,
              crossAxisAlignment: w.CrossAxisAlignment.start,
              children: [
                w.Text('Overlay #${entry.id}', style: entryStyle),
                w.Text(entry.name, style: label),
              ],
            ),
          ),
        );
      },
    );
  }

  @override
  w.Widget build(w.BuildContext context) {
    final theme = widget.theme;
    final label = theme.labelSmall.copy()..foreground(theme.onBackground);

    return w.Container(
      padding: const w.EdgeInsets.all(1),
      color: theme.background,
      child: w.Container(
        child: w.Scrollbar(
          controller: _scrollController,
          thickness: 1,
          gap: 1,
          enableHover: true,
          trackChar: ' ',
          thumbChar: ' ',
          trackUsesBackground: true,
          thumbUsesBackground: true,
          trackGradient: w.ScrollbarGradient.background(
            start: w.hasDarkBackground
                ? const BasicColor('#2f363d')
                : const BasicColor('#e3e7eb'),
            end: w.hasDarkBackground
                ? const BasicColor('#1f252a')
                : const BasicColor('#d3d9e0'),
          ),
          thumbGradient: w.ScrollbarGradient.background(
            start: w.hasDarkBackground
                ? const BasicColor('#3fb2ff')
                : const BasicColor('#2f7df6'),
            end: w.hasDarkBackground
                ? const BasicColor('#7c5cff')
                : const BasicColor('#6e55f5'),
          ),
          hoverThumbGradient: w.ScrollbarGradient.background(
            start: w.hasDarkBackground
                ? const BasicColor('#79ddff')
                : const BasicColor('#4f93ff'),
            end: w.hasDarkBackground
                ? const BasicColor('#b18bff')
                : const BasicColor('#836bff'),
          ),
          hoverThumbChar: ' ',
          child: w.ScrollView(
            controller: _scrollController,
            handleKeys: true,
            child: w.Column(
              gap: 1,
              crossAxisAlignment: w.CrossAxisAlignment.start,
              children: [
                w.Text('Overlay Widget Demo', style: theme.titleLarge),
                w.Text(
                  'a = add entry | r = remove last | c = clear | q = quit',
                  style: label,
                ),
                w.Text('Active entries: ${_entries.length}', style: label),
                w.Divider(width: 60),
                w.Text('Base Layer', style: theme.titleMedium),
                w.Text(
                  'This is the base layer of the Overlay.\n'
                  'Additional entries stack on top.\n'
                  'New cards appear as floating layers on the right.',
                  style: label,
                ),
                w.Divider(width: 60),
                if (_entries.isEmpty)
                  w.Text(
                    'No overlay entries. Press a to add one.',
                    style: label,
                  )
                else
                  w.Text(
                    'Entries (bottom to top): '
                    '${_entries.map((e) => e.name).join(", ")}',
                    style: label,
                  ),
              ],
            ),
          ),
        ),
      ),
    );
  }
}

class _EntryInfo {
  _EntryInfo({required this.id, required this.color, required this.name});
  final int id;
  final Color color;
  final String name;
}

Run it

dart run pkgs/artisanal_widgets/example/overlay/main.dart
