ClipRect Widget

Demonstrates using ClipRect to clip child content to a specified width and/or height without ellipsis.

Preview

Code

pkgs/artisanal_widgets/example/clip_rect/main.dart

// ClipRect Widget Example
import 'package:artisanal_widgets/artisanal_widgets.dart';
//
// Demonstrates using ClipRect to clip child content to a specified
// width and/or height without ellipsis.
//
// Run with: dart run example/clip_rect/main.dart

import 'package:artisanal/style.dart' hide Padding, Align;
import 'package:artisanal/tui.dart' as tui;
import 'package:artisanal_widgets/widgets.dart' as w;

void main() async {
  final app = WidgetApp(ClipRectExample());
  await tui.runProgram(
    app,
    options: const tui.ProgramOptions(
      altScreen: true,
      mouseMode: tui.MouseMode.allMotion,
    ),
  );
}

class ClipRectExample extends w.StatefulWidget {
  ClipRectExample({super.key});

  @override
  w.State createState() => _ClipRectExampleState();
}

class _ClipRectExampleState extends w.State<ClipRectExample> {
  final w.WidgetScrollController _scrollController = w.WidgetScrollController();

  @override
  w.Widget build(w.BuildContext context) {
    final theme = widget.theme;
    final label = theme.labelSmall.copy()..foreground(theme.onBackground);

    return w.Container(
      child: w.Scrollbar(
        controller: _scrollController,
        thickness: 1,
        gap: 1,
        enableHover: true,
        trackChar: ' ',
        thumbChar: ' ',
        trackUsesBackground: true,
        thumbUsesBackground: true,
        trackGradient: w.ScrollbarGradient.background(
          start: w.hasDarkBackground
              ? const BasicColor('#2f363d')
              : const BasicColor('#e3e7eb'),
          end: w.hasDarkBackground
              ? const BasicColor('#1f252a')
              : const BasicColor('#d3d9e0'),
        ),
        thumbGradient: w.ScrollbarGradient.background(
          start: w.hasDarkBackground
              ? const BasicColor('#3fb2ff')
              : const BasicColor('#2f7df6'),
          end: w.hasDarkBackground
              ? const BasicColor('#7c5cff')
              : const BasicColor('#6e55f5'),
        ),
        hoverThumbGradient: w.ScrollbarGradient.background(
          start: w.hasDarkBackground
              ? const BasicColor('#79ddff')
              : const BasicColor('#4f93ff'),
          end: w.hasDarkBackground
              ? const BasicColor('#b18bff')
              : const BasicColor('#836bff'),
        ),
        hoverThumbChar: ' ',
        child: w.ScrollView(
          controller: _scrollController,
          handleKeys: true,
          child: w.Column(
            gap: 1,
            children: [
              w.Text('ClipRect Widget', style: theme.titleLarge),
              w.Text('q: quit', style: label),
              w.Divider(width: 50),

              // Width clipping
              w.Text('Width clipping:', style: theme.titleMedium),
              w.Row(
                gap: 2,
                children: [
                  w.Column(
                    children: [
                      w.Text('Original:', style: label),
                      w.Text('Hello, World! This is a long string.'),
                    ],
                  ),
                  w.Column(
                    children: [
                      w.Text('Clipped to 15:', style: label),
                      w.ClipRect(
                        width: 15,
                        child: w.Text('Hello, World! This is a long string.'),
                      ),
                    ],
                  ),
                  w.Column(
                    children: [
                      w.Text('Clipped to 5:', style: label),
                      w.ClipRect(
                        width: 5,
                        child: w.Text('Hello, World! This is a long string.'),
                      ),
                    ],
                  ),
                ],
              ),

              w.Divider(width: 50),

              // Height clipping
              w.Text(
                'Height clipping (5 lines to 3):',
                style: theme.titleMedium,
              ),
              w.Row(
                gap: 4,
                children: [
                  w.Column(
                    children: [
                      w.Text('Original:', style: label),
                      w.Column(
                        children: [
                          w.Text('Line 1'),
                          w.Text('Line 2'),
                          w.Text('Line 3'),
                          w.Text('Line 4'),
                          w.Text('Line 5'),
                        ],
                      ),
                    ],
                  ),
                  w.Column(
                    children: [
                      w.Text('Clipped:', style: label),
                      w.ClipRect(
                        height: 3,
                        child: w.Column(
                          children: [
                            w.Text('Line 1'),
                            w.Text('Line 2'),
                            w.Text('Line 3'),
                            w.Text('Line 4'),
                            w.Text('Line 5'),
                          ],
                        ),
                      ),
                    ],
                  ),
                ],
              ),

              w.Divider(width: 50),

              // Both width and height
              w.Text(
                'Both width (10) and height (2):',
                style: theme.titleMedium,
              ),
              w.ClipRect(
                width: 10,
                height: 2,
                child: w.Column(
                  children: [
                    w.Text('A very long first line of text'),
                    w.Text('A very long second line of text'),
                    w.Text('Third line — clipped away'),
                  ],
                ),
              ),

              w.Divider(width: 50),

              // ClipRect inside a DecoratedBox
              w.Text('Inside a DecoratedBox:', style: theme.titleMedium),
              w.DecoratedBox(
                decoration: w.BoxDecoration(border: Border.rounded),
                child: w.ClipRect(
                  width: 20,
                  child: w.Text(
                    'This text is clipped to 20 columns inside a border',
                  ),
                ),
              ),
            ],
          ),
        ),
      ),
    );
  }

  @override
  tui.Cmd? handleUpdate(tui.Msg msg) {
    if (msg is tui.KeyMsg && msg.key.char == 'q') {
      return tui.Cmd.quit();
    }
    return null;
  }
}

Run it

dart run pkgs/artisanal_widgets/example/clip_rect/main.dart
