Table

The table example demonstrates the table bubble being used to display tabular data.

Preview

Code

pkgs/artisanal/example/tui/examples/table/main.dart

library;

import 'package:artisanal/bubbles.dart' as bubbles;
import 'package:artisanal/bubbles.dart'
    as tui
    hide
        CodeBlockCommentDelimiters,
        CodeLanguageProfile,
        Column,
        CommonKeyBindings,
        EditBuffer,
        EditHistoryCoalescePredicate,
        EditHistoryController,
        EditHistoryMarkerBuilder,
        EditHistoryStateEquals,
        EditorCoreConfig,
        EditorState,
        GraphemePredicate,
        GraphemeReader,
        Help,
        KeyBinding,
        KeyMap,
        PasteMsg,
        Row,
        Spinner,
        SpinnerModel,
        SpinnerTickMsg,
        Spinners,
        Text,
        TextCommandResult,
        TextCursorCommandResult,
        TextDecorationLayerKey,
        TextDecorationRange,
        TextDiagnosticRange,
        TextDiagnosticSeverity,
        TextDocument,
        TextDocumentChange,
        TextDocumentEditResult,
        TextEditResult,
        TextExtmark,
        TextExtmarkOptions,
        TextExtmarkPositionRange,
        TextExtmarksController,
        TextHighlightRange,
        TextHitResult,
        TextLineCommandResult,
        TextLineDecoration,
        TextLineStateCommandExtensions,
        TextLineStateSnapshot,
        TextOffsetStateCommandExtensions,
        TextOffsetStateDocumentEditingExtensions,
        TextOffsetStateSnapshot,
        TextPasteChunk,
        TextPasteChunkStep,
        TextPasteController,
        TextPasteMode,
        TextPastePlan,
        TextPasteReference,
        TextPasteReferenceStore,
        TextPasteSession,
        TextPatternDiagnosticRule,
        TextPosition,
        TextPositionDiagnosticRange,
        TextSelection,
        TextSyntaxBuildResult,
        TextSyntaxChangeWindow,
        TextSyntaxDecorationPatch,
        TextSyntaxLineWindow,
        TextSyntaxProvider,
        TextSyntaxSession,
        TextSyntaxSnapshot,
        TextView,
        TextViewLine,
        TextViewport,
        TextVisualCursorPosition,
        UndoCommandDecoder,
        UndoCommandJournalEntry,
        UndoManager,
        UndoableCommand;

import 'package:artisanal/style.dart';
import 'package:artisanal/tui.dart' as tui;

final _baseStyle = Style()
    .border(Border.normal)
    .borderForeground(const AnsiColor(240));

// #region table_usage
class TableDemoModel implements tui.Model {
  TableDemoModel(this.table);

  final tui.TableModel table;

  @override
  tui.Cmd? init() => null;

  @override
  (tui.Model, tui.Cmd?) update(tui.Msg msg) {
    if (msg is tui.KeyMsg) {
      final key = msg.key;
      final isRune = key.type == tui.KeyType.runes && key.runes.isNotEmpty;
      final rune = isRune ? key.runes[0] : -1;

      // Toggle focus on Esc.
      if (key.type == tui.KeyType.escape) {
        table.focused ? table.blur() : table.focus();
        return (this, null);
      }

      // Quit on q or Ctrl+C.
      if ((isRune && rune == 0x71) || (key.ctrl && rune == 0x63)) {
        return (this, tui.Cmd.quit());
      }

      // Enter prints the selected city.
      if (key.type == tui.KeyType.enter) {
        final city = table.selectedRow?[1] ?? '';
        return (this, tui.Cmd.printf("Let's go to %s!", [city]));
      }
    }

    final (newTable, cmd) = table.update(msg);
    return (TableDemoModel(newTable), cmd);
  }

  @override
  String view() => '${_baseStyle.render(table.view())}\n';
}
// #endregion

Future<void> main() async {
  final columns = [
    bubbles.Column(title: 'Rank', width: 4),
    bubbles.Column(title: 'City', width: 10),
    bubbles.Column(title: 'Country', width: 10),
    bubbles.Column(title: 'Population', width: 10),
  ];

  final rows = [
    ['1', 'Tokyo', 'Japan', '37,274,000'],
    ['2', 'Delhi', 'India', '32,065,760'],
    ['3', 'Shanghai', 'China', '28,516,904'],
    ['4', 'Dhaka', 'Bangladesh', '22,478,116'],
    ['5', 'São Paulo', 'Brazil', '22,429,800'],
    ['6', 'Mexico City', 'Mexico', '22,085,140'],
    ['7', 'Cairo', 'Egypt', '21,750,020'],
    ['8', 'Beijing', 'China', '21,333,332'],
    ['9', 'Mumbai', 'India', '20,961,472'],
    ['10', 'Osaka', 'Japan', '19,059,856'],
    ['11', 'Chongqing', 'China', '16,874,740'],
    ['12', 'Karachi', 'Pakistan', '16,839,950'],
    ['13', 'Istanbul', 'Turkey', '15,636,243'],
    ['14', 'Kinshasa', 'DR Congo', '15,628,085'],
    ['15', 'Lagos', 'Nigeria', '15,387,639'],
    ['16', 'Buenos Aires', 'Argentina', '15,369,919'],
    ['17', 'Kolkata', 'India', '15,133,888'],
    ['18', 'Manila', 'Philippines', '14,406,059'],
    ['19', 'Tianjin', 'China', '14,011,828'],
    ['20', 'Guangzhou', 'China', '13,964,637'],
    ['21', 'Rio De Janeiro', 'Brazil', '13,634,274'],
    ['22', 'Lahore', 'Pakistan', '13,541,764'],
    ['23', 'Bangalore', 'India', '13,193,035'],
    ['24', 'Shenzhen', 'China', '12,831,330'],
    ['25', 'Moscow', 'Russia', '12,640,818'],
    ['26', 'Chennai', 'India', '11,503,293'],
    ['27', 'Bogota', 'Colombia', '11,344,312'],
    ['28', 'Paris', 'France', '11,142,303'],
    ['29', 'Jakarta', 'Indonesia', '11,074,811'],
    ['30', 'Lima', 'Peru', '11,044,607'],
    ['31', 'Bangkok', 'Thailand', '10,899,698'],
    ['32', 'Hyderabad', 'India', '10,534,418'],
    ['33', 'Seoul', 'South Korea', '9,975,709'],
    ['34', 'Nagoya', 'Japan', '9,571,596'],
    ['35', 'London', 'United Kingdom', '9,540,576'],
    ['36', 'Chengdu', 'China', '9,478,521'],
    ['37', 'Nanjing', 'China', '9,429,381'],
    ['38', 'Tehran', 'Iran', '9,381,546'],
    ['39', 'Ho Chi Minh City', 'Vietnam', '9,077,158'],
    ['40', 'Luanda', 'Angola', '8,952,496'],
    ['41', 'Wuhan', 'China', '8,591,611'],
    ['42', 'Xi An Shaanxi', 'China', '8,537,646'],
    ['43', 'Ahmedabad', 'India', '8,450,228'],
    ['44', 'Kuala Lumpur', 'Malaysia', '8,419,566'],
    ['45', 'New York City', 'United States', '8,177,020'],
    ['46', 'Hangzhou', 'China', '8,044,878'],
    ['47', 'Surat', 'India', '7,784,276'],
    ['48', 'Suzhou', 'China', '7,764,499'],
    ['49', 'Hong Kong', 'Hong Kong', '7,643,256'],
    ['50', 'Riyadh', 'Saudi Arabia', '7,538,200'],
    ['51', 'Shenyang', 'China', '7,527,975'],
    ['52', 'Baghdad', 'Iraq', '7,511,920'],
    ['53', 'Dongguan', 'China', '7,511,851'],
    ['54', 'Foshan', 'China', '7,497,263'],
    ['55', 'Dar Es Salaam', 'Tanzania', '7,404,689'],
    ['56', 'Pune', 'India', '6,987,077'],
    ['57', 'Santiago', 'Chile', '6,856,939'],
    ['58', 'Madrid', 'Spain', '6,713,557'],
    ['59', 'Haerbin', 'China', '6,665,951'],
    ['60', 'Toronto', 'Canada', '6,312,974'],
    ['61', 'Belo Horizonte', 'Brazil', '6,194,292'],
    ['62', 'Khartoum', 'Sudan', '6,160,327'],
    ['63', 'Johannesburg', 'South Africa', '6,065,354'],
    ['64', 'Singapore', 'Singapore', '6,039,577'],
    ['65', 'Dalian', 'China', '5,930,140'],
    ['66', 'Qingdao', 'China', '5,865,232'],
    ['67', 'Zhengzhou', 'China', '5,690,312'],
    ['68', 'Ji Nan Shandong', 'China', '5,663,015'],
    ['69', 'Barcelona', 'Spain', '5,658,472'],
    ['70', 'Saint Petersburg', 'Russia', '5,535,556'],
    ['71', 'Abidjan', 'Ivory Coast', '5,515,790'],
    ['72', 'Yangon', 'Myanmar', '5,514,454'],
    ['73', 'Fukuoka', 'Japan', '5,502,591'],
    ['74', 'Alexandria', 'Egypt', '5,483,605'],
    ['75', 'Guadalajara', 'Mexico', '5,339,583'],
    ['76', 'Ankara', 'Turkey', '5,309,690'],
    ['77', 'Chittagong', 'Bangladesh', '5,252,842'],
    ['78', 'Addis Ababa', 'Ethiopia', '5,227,794'],
    ['79', 'Melbourne', 'Australia', '5,150,766'],
    ['80', 'Nairobi', 'Kenya', '5,118,844'],
    ['81', 'Hanoi', 'Vietnam', '5,067,352'],
    ['82', 'Sydney', 'Australia', '5,056,571'],
    ['83', 'Monterrey', 'Mexico', '5,036,535'],
    ['84', 'Changsha', 'China', '4,809,887'],
    ['85', 'Brasilia', 'Brazil', '4,803,877'],
    ['86', 'Cape Town', 'South Africa', '4,800,954'],
    ['87', 'Jiddah', 'Saudi Arabia', '4,780,740'],
    ['88', 'Urumqi', 'China', '4,710,203'],
    ['89', 'Kunming', 'China', '4,657,381'],
    ['90', 'Changchun', 'China', '4,616,002'],
    ['91', 'Hefei', 'China', '4,496,456'],
    ['92', 'Shantou', 'China', '4,490,411'],
    ['93', 'Xinbei', 'Taiwan', '4,470,672'],
    ['94', 'Kabul', 'Afghanistan', '4,457,882'],
    ['95', 'Ningbo', 'China', '4,405,292'],
    ['96', 'Tel Aviv', 'Israel', '4,343,584'],
    ['97', 'Yaounde', 'Cameroon', '4,336,670'],
    ['98', 'Rome', 'Italy', '4,297,877'],
    ['99', 'Shijiazhuang', 'China', '4,285,135'],
    ['100', 'Montreal', 'Canada', '4,276,526'],
  ];

  final table = tui.TableModel(columns: columns, rows: rows, focused: true)
    ..setHeight(8)
    ..setStyles(
      tui.TableStyles(
        header: tui.TableStyles.defaults().header
            .foreground(const AnsiColor(240))
            .bold(false),
        selected: tui.TableStyles.defaults().selected
            .foreground(const AnsiColor(229))
            .background(const AnsiColor(57))
            .bold(false),
      ),
    );

  await tui.runProgram(
    TableDemoModel(table),
    options: const tui.ProgramOptions(altScreen: false, hideCursor: false),
  );
}

Run it

dart run pkgs/artisanal/example/tui/examples/table/main.dart
